Description
The EchoOrbit® ceiling sail is the perfect solution to acoustical calm noisy rooms. Three-dimensional diamond facets dampen the noise level and act as a diffuser for sound waves. Additional elements can be added seamlessly thanks to the hexagonal shape, allowing for stunning ceiling designs with spectacular arrangements and colour combinations. Installation is efficient thanks to only one height-adjustable suspension per element and supplied fasteners.Say goodbye to unwanted noise and immerse yourself in a heavenly, futuristic silence with EchoOrbit®.
Furniture Fixtures And Equipment
Acoustical/Ceilings
Architectural
Ceiling/Ceiling Systems
Size
1800 mm (± 1 mm) x 2380 mm (± 1 mm)
Content
PET Felt
Total Weight
3600 g/m² (± 10%)
Overall Thickness
24 mm
Can be cleaned dry and damp with chlorine or hydrogen peroxide
Indoor & Outdoor
Indoor
Installation
Simple and quick installation. Suitable for use indoors as well as covered outdoor areas. Very easy to trim with a knife. Easy to adjust in height and to fasten with screws. At least 20cm distance to the ceiling. Refer Installation PDF for More Details
Manufacturer Notes
303 PET Bottles *The number of PET bottles refers to 500ml PET bottles with a bottle weight of 24g
Flammability
EN 13501 B-s2, d0
Lightfastness
ISO 105-B02-1994 - > 7
Emissions
VOC Emission: ASTM D5116 - < 0.5mg/m2/h; Formaldehyde Emissions: ASTM D5116 - < 0.1mg/m2/h
Acoustics
DIN EN ISO 11654 ASTM C423 - aw 0.50 (direct mount), aw 0.65 (50mm wall/ceiling distance), aw 1.00 (200mm wall/ceiling distance), NRC = 0.70 (direct mount), NRC = 0.80 (50mm wall/ceiling distance), NRC = 0.95 (200mm wall/ceiling distance)
Performance
Melting Point: 250 °C; Decomposition Temp: > 250 °C; Alkalinity: pH: 7.8 (pH 7 is neutral)
Climate Impact
Cradle to Cradle Bronze, Manufacturer Take-Back Program, Recycled Content - Post-Consumer, Recycled Content
Human Health Impact
CDPH / CHPS 01350 Compliant, Low Emitting/Low VOC, M1 Emissions Classification, WELL Compliant
VOC Emissions Testing Methodology
CDPH / CHPS 01350 Compliant
End-of-Life Options
Manufacturer Take-Back Program

ECHOJAZZ

ECHOJAZZ — Acoustic inspiration: We provide custom-made, high-performance acoustic absorbers for a strong improvement of comfort and room quality. ECHOJAZZ EchoBoards® are fabricated by recycled polyethylene terephthalate bottles that is 100% Swiss design and create zero waste.
