Description
Reducing reverberated noise in shared spaces, these tactile acoustic panels are ideal for floor to ceiling applications, and pattern match for continuous wall and double-height installations. The embossed panel series is manufactured using at least 51% recycled content and utilising green energy. The collection is Global GreenTag™ certified, has published ingredient transparency through Declare and low VOC emissions.
Furniture Fixtures And Equipment
Acoustical/Panels & Tiles; Acoustical/Walls
Architectural
Ceiling/Ceiling Systems
Size
2800 mm (+/-3 mm) x 1130 mm (+/- 3 mm)
Warranty
5 Years
Content
PET Felt
Construction
Embossed
Format
Panel / Sheet
Total Weight
8.13 kg
Overall Thickness
9 mm (+/- 7%)
Please refer Care and Cleaning Guide PDF for more details
Indoor & Outdoor
312
Applications
Walls, Ceilings, Workstation Screens, Space Dividers
Installation
Our Embossed Panel Series can be installed on walls and ceilings. At 2.8m high, they can be applied to walls without a floor-to-ceiling join line. Designs pattern-match side to side and top to bottom, making them suitable for continuous wall and double height installations. Please refer Installation Guide PDF for more details
Flammability
ASTM E84 Unadhered: Class 1 or A, ISO 9705: Group 1, BS EN 13501.1: Classification B - s1, d0
Lightfastness
ISO 105 B02 Rating: 6
Emissions
ASTM D5116: TVOC Emissions Rate: <0.015mg/m²/hr (7 days) and CDPH Standard Method v1.2: TVOC Emissions Rate: <0.010mg/m³; Formaldehyde Emissions Rate: <5µg/m³
Acoustics
AS ISO 354: 2006 (R2016), ASTM C423 - 17, AS ISO 11654: 2002 (2016); Refer to Sound Absorption PDFs for more information including NRC, SAA, and aw ratings
Climate Impact
Recycled Content - Pre-Consumer, Global GreenTag Certified, Recycled Content
Human Health Impact
Declare Label - Red List Free, Low Emitting/Low VOC, UL GREENGUARD
Post-Industrial Recycled Content Percentage
51%
Material Health Certifications
Declare Label - Red List Free
VOC Emissions Testing Certificate
UL Greenguard Certified or Gold

Woven Image

Woven Image supplies the commercial built environment with sustainable, design-led acoustic finishes. From the invention of the original 60% recycled PET acoustic panel, EchoPanel®, to the embossed range, they continue to lead market colour and design trends through new wall and ceilings finishes.
